INDUCTION MOTORS | 160 KW | 215 HP | 4P | IE4 | B3 | NON-FLAMEPROOF
Login to view prices
INDUCTION MOTORS | 200 KW | 270 HP | 4P | IE4 | B3 | NON-FLAMEPROOF
Login to view prices
INDUCTION MOTORS | 180 KW | 240 HP | 4P | IE4 | B3 | NON-FLAMEPROOF
Login to view prices
| Weight | 10 kg |
|---|---|
| Brand |
Verlec |
| L1 |
Motors – Pumps |
| L2 |
Motors |
| L3 |
Induction motors |
| Rating - KW |
180 |
| Rating - hp |
240 |
| Pole |
4 |
| Efficiency Class |
IE4 |
| Mounting Type |
B3 |
| Flameproof |
Non-Flameproof |
| Voltage - V |
415 |
| Frequency - hz |
50 |
| Variation - % |
10 |
| Altitude - m |
1000 |
| Frame Size |
315L |
| Starting Type |
DOL |
| Enclosure |
TEFC |
| Degree of Protection |
IP55 |
| Insulation Class |
F |
| Winding Treatment |
VPI |
| MOC of Casing |
Cast iron |
| Forced cooling arragement |
NA |
| Bearing Insulation |
NA |
| Duty |
S1 |
| Standard |
IS12615 |
| Type of cooling |
TEFC |
| Stator connection |
STAR |
| Type of starting |
DOL |
| Standard cable size - sqmm |
185 |
| Rotation from DE |
BIDIRECTIONAL |
| Bearing - DE |
6319 C3 |
| Bearing - NDE |
6218 C3 |
| Bearing Life - DE |
40000 |
| Bearing Life - NDE |
40000 |
| Lubrication |
Self |
| Fault level of TB |
50 KA for 0.25 sec with suitable fuses |
| Rated Current - A |
291 |
| Full load speed - RPM |
1485 |
| Starting Current(% of FLC) |
890 |
| Efficiency (FL) |
96.7 |
| Efficiency (3/4 L) |
95.9 |
| Efficiency (1/2 L) |
94.8 |
| Power factor (FL) |
0.89 |
| Power factor (3/4 L) |
0.85 |
| Power factor (1/2 L) |
0.76 |
| Ambient Temp - C |
50 |
| Temp rise (K) |
70 |
| Rated Torque - kgf-m |
118.06 |
| Starting Torque - kgf-m |
220 |
| Pull-out Torque - kgf-m |
275 |
| Ther WS time - Hot - s |
15 |
| Ther WS time - Cold - s |
33 |
| Ther heat time (Hot) - min |
63 |
| Ther heat time (Cold) - min |
188 |
| App start time - 100% V - s |
Depends on load |
| App start time - 80% V - s |
depends on load |
| Momentary excess torque - % |
1.2 |
| Rotor GD² - kg/m2 |
31.68 |
| Max.permissible load GD^2 |
421 |
| Load GD SQ.(kg/m2) |
customer to provide |
| Vibration (At No Load) |
IS 12075 |
| Sound pressure load - dB(A) |
IS 12065 |
| Noise (At No Load) |
IS 12065 |
| Warranty |
24 Months |
| Packaging |
Wooden Box |
